Retro ASCII Art

Concept: Retro 3D Art

Retro Computer Graphics from Behance

I was inspired by old school computer graphics that you would see in movies like The Matrix. Because of this, I knew that I wanted to make some ASCII art in the signature green color that most retro graphics used. After some experimenting, I decided to make an ASCII representation of a Menger Sponge, which is a fractal geometry that I thought would be very interesting to look at.

Process

I began by creating a sample video that I could use to turn into ASCII art. To do this, I created a 3D cube in Processing, which is a predecessor of P5.js. I attempted to do this in P5.js, but found the saveFrame() function too limiting. I created a simple box using the 3D renderer in Processing, and added some lighting to give the sketch some dynamic range. This is important as I needed to use the difference in brightness later on when converting the video to ASCII, and the greater the dynamic range is the easier it is to perceive the ASCII video.

void setup() {
  size(600, 600, P3D);
}

float a = 0;
void draw() {
  background(0);
  noStroke();
  spotLight(10, 80, 240, width/2, height/2, 400, 0, 0, -1, PI/4, 2);
  pointLight(255, 0, 0, width/2, height/2, height/2);
  ambientLight(100, 0, 100);
  fill(255);

  translate(width/2, height/2);
  rotateX(a/2);
  rotateY(a/2);
  rotateZ(a/3);
  box(280);

  a+=PI/100;

  saveFrame("src/box-######.png");
}

I incremented the rotation angle by a fraction of pi because I wanted to be able to count when the cube resets to its original position. This made it easier to create a video that could be looped seamlessly.

Once I had the output frames, I combined them together using Microsoft Movie Maker. The final result was this video:

Next, I wanted to work on converting this footage to ASCII art. I followed Daniel Schiffman’s coding challenge on creating ASCII text images. After experimenting with the video size and character density arrays, the following sketch was the result I got:

However, I wanted to create something a bit more complex. This is when I remembered an old project that I worked on by following another one of The Coding Train‘s challenges, which was the Menger Sponge coding challenge.  After generating the frames and compiling them into a video, this was the result:

All I had to do then is to insert this video into the original code and play around with different parameters until I got the desired result.

Code Highlights

I’m really proud of the code that makes the animation look like its being built up slowly using ASCII characters. The way I achieved this is basically by filtering out the highlights on the Menger sponge. When I compiled the video, I saw that the lower right corner of the sponge had a bright highlight on it that was blocky.

//finding the right character based on brightness of pixel
let len = charArray.length;
let charIndex;

//playing with map values for the building up effect
charIndex = floor(map(apparentBrightness, 0, 100, len, 0));

When I filtered the brightest points of the sponge out, I essentially removed the lower left corner until it got a bit darker later in the animation, which created the building-up effect.

Reflection

Compared to the first assignment, I had a more solid idea of what I wanted to achieve. Because of this, I had planned out my workflow beforehand and that streamlined the entire creative process. I knew I had to create source animation and then convert it to ASCII characters. This made my code more readable, and I had better control of the sketch overall.

However, the building-up animation that I am most proud of is dependent on the source video. It looks the way it is because in the source animation the highlights are blocky as well. If I wanted to recreate this project, I want to work on some logic that allows the effect to be more generalizable. Maybe I could filter out sections of the object based on a distance function instead of the brightness levels. That way I can substitute different source videos and still get the cool effect.

Sources





Featured

Analog Musical Instrument

const int blueButton = 6;
const int servoPin = 9;
const int songLength = 8;
const int tempo = 115;

const int noteC3 = 130;
const int noteD3 = 146;
const int noteE3 = 164;
const int noteF3 = 174;
const int noteG3 = 196;
const int noteA3 = 220;
const int noteB3 = 246;


const int noteC4 = 261;
const int noteD4 = 293;
const int noteE4 = 329;
const int noteF4 = 349;
const int noteG4 = 392;
const int noteA4 = 440;
const int noteB4 = 493;
const int noteC5 = 523;

const int noteD5 = 587;
const int noteE5 = 659;
const int noteF5 = 698;
const int noteG5 = 784;
const int noteA5 = 880;
const int noteB5 = 987;


//int musicNotes[] = {noteC4, noteD4, noteE4, noteF4, noteG4, noteA4, noteB4, noteC5};
int musicNotes[] = {noteC5, 0, noteE5, 0, noteG5, 0, noteB5, 0};
int musicNotes2[] = {noteC4, 0, noteE4, 0, noteG4, 0, noteB4, 0};
int musicNotes3[] = {noteC3, 0, noteE3, 0, noteG3, 0, noteB3, 0};
int noteDuration[] = {2, 4, 2, 4, 4, 2, 4, 2};

void setup() {
  pinMode(servoPin, OUTPUT);
  pinMode(blueButton, INPUT_PULLUP);
  Serial.begin(9600);
}
void loop() {
 lightSensor();
  button();



}

//new tab: button
void button() {


  bool bluebuttonState = digitalRead(blueButton);
  if (bluebuttonState == HIGH) {
    for (int i = 0; i < songLength; i++) {

      int duration =   noteDuration[i] * tempo;

      tone(servoPin, musicNotes2[i], duration);
      delay(duration); //make the length of the time = length of the musical note(frequency)
      delay(15);

    }
  }    else {
    for (int i = 0; i < songLength; i++) {

      int duration =   noteDuration[i] * tempo;

      tone(servoPin, musicNotes[i], duration);
      delay(duration); //make the length of the time = length of the musical note(frequency)
      delay(15);


    };


  };

};
//new tab light sensor
void lightSensor() {
  int analogValue = analogRead(A0);
 Serial.print(analogValue);
  if (analogValue < 10) {
   Serial.println(" - Dark");
//   //add music note here
  } else if (analogValue < 200) {
   Serial.println(" - Dim");
    for (int i = 0; i < songLength; i++) {

     int duration =   noteDuration[i] * tempo;

     tone(servoPin, musicNotes3[i], duration);
     delay(duration); //make the length of the time = length of the musical note(frequency)
     delay(15);

    }

  }  };


Documentation:

Idea: Create sound directly from Arduino, like a musical drone sound by changing the musical notes from C4 to C5 when you click on the button or change from either to a 3rd octave when you dim the light sensor (all by changing the frequency from within the motor).

Positives:

I like how I could manipulate the motor sound based on its frequency to create a tone and tempo.In addition to that I was able to play around with that frequency within the motor to create an array of musical notes with different octaves. Once I could adjust the tempo and time spacing between notes through looping the array, I was able to integrate that into different parts of the code.

I like that I was able to introduce different noises from the motor by adding in different components that trigger different sounds like the button and sensor.

This was also surprisingly fun compared to other assignments for me because I learned that Arduino could be used for more than just LED circuits etc but you can incorporate and manipulate other media like sound.

Negatives:

I don’t think its particularly musical, however I think it follows the rules of music in terms of octaves and musical notes.





Featured

Candy colored spiral visual effect

This has gone through many iterations of trial and error to get the coolest effect.

Im using spiraled ellipses as a main element for my mid term, so I have been experimenting with it.

Code for creating the spiral:

float angle;

float x;
float y;
void setup() {
  size(800, 800);
  noFill();
  shapeMode(CENTER);
}

void draw() {

  //fill(255);
   fill(255,200,200); //pale rose, change the color of the candy.
  ellipse(height/2, width/2, 600, 600);

  int hundred=100;
  //rotate(angle);

  for (int i=0; i<500; i+=100)

  {
    strokeWeight(20);
    stroke(0); //change the color of the spiral
    noFill();
    ;
    arc(height/2, width/2, hundred+i, hundred+i, radians(180), radians(360) );
    arc(height/2-25, width/2, hundred*1.5+i, hundred*1.5+i, radians(0), radians(180));
  }
  //angle=angle+0.1;
  //save("mySpiral.jpg");
};

I exported the code above to a .jpg format to use as an image in the sketch below.

Code for the animation:

float angle;
PImage img;
void setup() {
  size(900, 900);
  img = loadImage("mySpiral.png");
};
void draw() {
    background(255);
  for (int i=0; i<width; i++) {

     translate(width/2+i, height/2+i);
  imageMode(CENTER);
  rotate(angle);
  image(img, 0, 0,300,300);


  }
 angle=angle+1*1;
}



Next step :

I would like each candy spiral to go through several colored versions of itself:



  for (int a= 0; a<1; a++) {
     save(random(20)+"spiral");
  }

This code allows different colored versions from random to be saved as a new version of itself , I plan on using the saved photos as part of a sprite sheet to add to the animation above.

Featured

Psychedelic Geometry :)

float angle;
float grid= 400;
float i=0;
void setup() {
  size(1080, 900,P3D);
};

void draw() {

  for(int x=0;x<=width;x+=grid){
    for(int y=0;y<=height;y+=grid){
  translate(mouseX,mouseY);
rotateX(radians(angle));
rotateY(radians(angle));
i=0;
  while(i<width){
    i=i+20;
  beginShape();
vertex(i+100,100);
vertex(i+175,50);
vertex(i+250,100);
vertex(i+250,200);
vertex(i+175,250);
vertex(i+100,200);
vertex(i+100,100);
vertex(i+100,200);

endShape();
  };

  };
  };
//rotateX(radians(angle));
angle+=1; //does a full rotation
};

For this assignment,

I went through A LOT of experimentation,

at first, I wanted to recreate this pattern:

I almost got there:

Then, I didn’t really know what to do with it in terms of animation….

I  discovered the built in P3D  and started different experiments, but  I didn’t know how to integrate more effects while using the While loop, so I experimented further and created the animation at the top of the post.

The inspiration of this post for me was to experiment as much as possible, since it’s been helping me understand the mechanics of the code. And to save different blocks of code on GitHub if I find something interesting I could integrate in a different art piece later.
